Performance | Image Sensor | 752×480 CMOS |
Light Source | Red LED 625±10 nm |
Symbologies | 2D | PDF417, QR Code (QR1/2, Micro), Data Matrix (ECC200, ECC000, 050, 080, 100, 140), Chinese Sensible Code |
1D | Code128, UCC/EAN-128, AIM128, EAN-8, EAN-13, ISBN/ISSN, UPC-E, UPC-A, Interleaved 2 of 5, ITF-6, ITF-4, Matrix 2 of 5, Industrial 25, Standard 25, Code 39, Codabar, Code 93, Code 11, Plessey, MSI-Plessey, GS1-DataBarTM(RSS), (RSS-14, RSS-Limited, RSS-Expand) |
Resolution | ≥5mil |
Typical Depth of Field | EAN-13 50mm-445mm (13mil) |
PDF417 70mm-160mm (6.67mil) |
Code 39 50mm-215mm (5mil) |
Data Matrix 60mm-150mm (10mil) |
QR Code 35mm-210mm (15mil) |
Symbol Contrast | ≥25% reflectance difference |
Scan Angle | Roll: 360°, Pitch: ±55°, Skew: ±55° |
Field of View | Horizontal 36°, Vertical 23° |
Mechanical/ Electrical | Interface | TTL-232, USB (HID-KBW, COM Port Emulation, HID-POS) |
Operating Voltage | 3.0~3.6VDC |
Current @3.3VDC | Operating 190mA |
Standby | 7mA |
Sleep | <5uA |
Dimensions | 28.0(W)×24.5(D)×13.9(H)mm |
Weight | 9.5g |
Environmental | Operating Temperature | -20℃~+55℃(-4°F~131°F) |
Storage Temperature | -40℃~+80℃(-40°F~176°F) |
Humidity | 5%~95% (non-condensing) |
Ambient Light | 0~100000lux (natural light) |
Accessories | EVK | Software development board equipped with a trigger button, beeper and RS-232 & USB interfaces. |
Cable | USB | Used to connect the EVK to a host device. |
RS-232 | Used to connect the EVK to a host device. |
Power Adaptor | Used to provide power for the EVK Output: DC5V, 1A; Input: AC100~240V, 50~60Hz |
